Specifications

• CO2 Sensor Measurement 0-5% (0-50,000 ppm)
• O2 Sensor Range 0-25%
• Alarms (CO2) 5,000 ppm TWA, 5,000 ppm, 3% (user configurable)
• Alarms (O2) 19.5%, 16.5%, 12%
• Measurement Interval 2 seconds (0.5 Hz)
• Operating Temperature 32-122° F (0-50° C)
• Connections Standard RJ45
  Sensor Coverage Approximately 1,500 sq. ft.

Electrical and Mechanical Specifications

• Power Supply 100-240 VAC 50/60 Hz to 12 VDC power adapter
• Voltage Range 9-32VDC
• Power Consumption 3 Watts
• Audible Alarm Level 88dB
• Relay Power Rating Peak current <2A @ 30 VDC or 250 VAC, SPDT
• Relay Connection Screw Terminal Connection
